FLOW PACK / HFFS

Horizontal Flow Pack machines

Choose how your product travels, then choose the machine. Top-reel and bottom-reel flow wrappers differ in film feed, product handling and the position of the longitudinal fin seal.

  • Top reel: the film is fed from above and the fin seal is formed underneath the pack. Suitable for stable, rigid products such as biscuits, bars and trays.
  • Bottom reel: the product rests directly on the film and the fin seal is formed on top of the pack. Suitable for fragile, soft or irregular products and multipacks.

The final choice should be tested with the intended product, film and line configuration.

01 / TOP REEL

Top-reel Flow Pack machines

The film is fed from above and formed around the product, with the longitudinal seal underneath the pack. The infeed system guides the items towards the former.

An option to assess for stable products such as bars, biscuits, rigid trays, soap and technical items. Check fragility and feeding suitability on actual samples.

02 / BOTTOM REEL

Bottom-reel or inverted Flow Pack machines

The film is fed from below and supports the product during transport. The longitudinal seal is on top of the pack.

A configuration to assess for soft, delicate, irregular or grouped items, including produce and bakery products. Moisture, residues and any need for supporting trays must be checked.

Top reel or bottom reel: where to start

What to assess Top reel Bottom reel / inverted
Product transport Guided along the infeed surface towards the former Supported by the film during transport
Longitudinal seal Under the pack On top of the pack
First selection criterion Product stability and suitability for the infeed system Delicacy or difficulty with sliding and pushing
Required checks Actual product, film, pack format, target speed and line integration

These criteria guide selection, but do not replace a machine trial. Performance and compatibility depend on the chosen configuration.

Film and sealing systems

Materials indicated by Imbal Stock include coextruded BOPP, polyethylene-coated paper and barrier films for protective-atmosphere applications. PP and PE sealing systems can be assessed on request, particularly for bottom-reel configurations.

Compatibility is model-specific. Film thickness, sealability and behaviour on the actual product must be checked.

Explore MAP packaging solutions →

Applications and line integration

Food, pet food, cosmetics and technical items have different handling requirements. For loose products or larger fill weights, compare vertical packaging machines. For grouped packs, consider shrink wrappers or sleeve wrappers.

Feeding, counting and downstream equipment should be considered as part of the complete packaging line.

Explore food applications and pet food applications.

Frequently asked questions

Is a bottom-reel machine always needed for wet products?

It may be worth assessing because the product is supported by the film, but moisture alone does not determine the choice. Shape, consistency, residues, feeding and pack requirements must be tested with actual samples.

How fast can a Flow Pack machine run?

Output depends on the model, format, film, feeding system and product. Datasheet ranges describe specific configurations; the required line speed must be verified under the intended operating conditions.

Can the same machine use different films?

This depends on the configuration and sealing systems installed. Before changing material, check sealability, thickness, film handling and behaviour around the product.

Test the packaging with your product

Tell us your product, dimensions, film and target output. Imbal Stock will arrange a sample trial to assess pack appearance, sealing quality and the operating speed of the proposed configuration.
